| Mechanical Characteristics | |
| Cell Type | P type Mono-crystalline |
| No. of cells | 144 (6×24) |
| Dimensions | 2278×1134×30mm (89.69×44.65×1.18 inch) |
| Weight | 31 kg (68.34bs) |
| Front Glass | 2.0mm, Anti-Reflection Coating |
| Back Glass | 2.0mm, Heat Strengthened Glass |
| Frame | Anodized Aluminium Alloy |
| Junction Box | IP68 Rated |
| Output Cables | TUV 1×4.0mm² (+): 400mm, (-): 200mm or Customized Length |
